Standard Technical Specification
| Models | Tube Outer Diameter | Strip Width | Wall Thickness | Line Speed |
|---|---|---|---|---|
| Round | ||||
| mm | mm | mm | m/min | |
| DMC-VA10A | 10.0 ~ 25.4 | 30 ~ 80 | 0.6 ~ 2.3 | Max. 150 |
|
DMC-VA11A DMC-VA11B |
10.0 ~ 31.8 12.7 ~ 38.1 |
30 ~ 100 40 ~ 120 |
0.6 ~ 2.6 0.8 ~ 2.6 |
Max. 150 Max. 150 |
|
DMC-VA12A DMC-VA12B DMC-VA12C |
21.7 ~ 63.5 21.7 ~ 63.5 21.7 ~ 63.5 |
70 ~ 200 70 ~ 200 70 ~ 200 |
0.8 ~ 2.6 1.0 ~ 3.2 1.2 ~ 4.5 |
Max. 150 Max. 150 Max. 130 |
| DMC-VA21A | 25.4 ~ 63.5 | 80 ~ 200 | 1.4 ~ 6.0 | Max. 120 |
|
DMC-VA22A DMC-VA22B DMC-VA22C |
25.4 ~ 76.3 31.8 ~ 76.3 38.1 ~ 76.3 |
80 ~ 240 100 ~ 240 120 ~ 240 |
1.0 ~ 4.0 1.4 ~ 6.0 1.4 ~ 8.0 |
Max. 120 Max. 120 Max. 100 |
|
DMC-VA23A DMC-VA23B DMC-VA23C |
31.8 ~ 89.1 31.8 ~ 89.1 31.8 ~ 89.1 |
100 ~ 280 100 ~ 280 100 ~ 280 |
1.4 ~ 4.5 1.4 ~ 6.0 1.4 ~ 9.0 |
Max. 120 Max. 100 Max. 100 |
|
DMC-VA24A DMC-VA24B DMC-VA24C DMC-VA24D |
38.1 ~ 114.3 38.1 ~ 114.3 38.1 ~ 114.3 38.1 ~ 114.3 |
120 ~ 360 120 ~ 360 120 ~ 360 120 ~ 360 |
1.4 ~ 4.5 1.4 ~ 6.0 1.4 ~ 9.0 2.3 ~ 11.0 |
Max. 100 Max. 100 Max. 90 Max. 80 |
|
DMC-VA31A DMC-VA31B DMC-VA31C DMC-VA31D DMC-VA31E |
38.1 ~ 127.0 38.1 ~ 127.0 42.7 ~ 139.8 42.7 ~ 139.8 42.7 ~ 139.8 |
120 ~ 400 120 ~ 400 135 ~ 440 135 ~ 440 135 ~ 440 |
1.2 ~ 4.5 1.2 ~ 6.0 1.4 ~ 4.5 1.4 ~ 6.0 1.4 ~ 9.0 |
Max. 100 Max. 70 Max. 70 Max. 70 Max. 60 |
|
DMC-VA32A DMC-VA32B DMC-VA32C |
50.8 ~ 168.3 50.8 ~ 168.3 50.8 ~ 168.3 |
160 ~ 530 160 ~ 530 160 ~ 530 |
1.4 ~ 6.0 2.0 ~ 8.0 2.3 ~ 10.0 |
Max. 70 Max. 60 Max. 60 |
|
DMC-VA33A DMC-VA33B DMC-VA33C |
60.5 ~ 190.7 60.5 ~ 190.7 60.5 ~ 190.7 |
190 ~ 600 190 ~ 600 190 ~ 600 |
1.4 ~ 6.0 2.0 ~ 8.0 2.3 ~ 10.0 |
Max. 60 Max. 60 Max. 60 |
